GRAPHIC PRINTING
ESC * t
n
R
ESC * t 75 R
ESC * t 100 R
ESC * t 150 R
ESC * t 300 R
ESC * r
n
S
ESC * b 0 M
ESC * b 1 M
ESC * b 2 M
ESC * b 3 M
ESC * r
n
Q
ESC * r 0 Q
ESC * r 1 Q
ESC * r 2 Q
ESC * r 9 Q
27 42 116
n
82
27 42 116 55 53 82
27 42 116 49 48 48
82
27 42 116 49 53 48
82
27 42 116 51 48 48
82
27 42 114
n
83
27 42 98 48 77
27 42 98 49 77
27 42 98 50 77
27 42 98 51 77
27 42 114
n
81
27 42 114 48 81
27 42 114 49 81
27 42 114 50 81
27 42 114 57 81
1B 2A 74
n
52
1B 2A 74 37 35 52
1B 2A 74 31 30 30
52
1B 2A 74 31 35 30
52
1B 2A 74 33 30 30
52
1B 2A 72
n
53
1B 2A 62 30 4D
1B 2A 62 31 4D
1B 2A 62 32 4D
1B 2A 62 33 4D
1B 2A 72
n
51
1B 2A 72 30 51
1B 2A 72 31 51
1B 2A 72 32 51
1B 2A 72 39 51D
Graphic Resolution
75 dpi print density
100 dpi print density
150 dpi print density
300 dpi print density
Graphic Printing Width
(
n
depends on the
width of the image
created and is limited
by the page width)
Normal Graphic
Printing
Compacted Mode 1
Compacted Mode 2
Compacted Mode 3
Graphic Printing Quality
Default value (LQ)
Economy
Letter Quality
Draft
ESC * r
n
A
ESC * b
n
W..
27 42 114
n
65
27 42 98
n
87 ..
1B 2A 72
n
41
1B 2A 62
n
57 ..
Start Graphic Printing
(
n
= 0, start at left
margin;
n
=1,startat
current cursor position)
Send Data for Graphic
Printing (
n
is the data
for one pixel raster row)
ESC * b
n
X 274298
n
88 1B 2A 62
n
58 Horizontal (X) Offset
(
n
is a number of blank
dots - a multiple of
eight - inserted,
starting from the left
hand margin, at the
beginning of the raster
row; one dot = 1/300 in)
(continued)
GRAPHIC PRINTING (continued)
ESC * b
n
Y
ESC * r B
27 42 98
n
89
27 42 114 66
1B 2A 62
n
59
1B 2A 72 42
Vertical (Y) Offset
(
n
is a number of blank dots -
a multiple of eight - inserted
before the raster row, starting
from the top margin; one dot =
1/300 in)
End Graphic Printing
OTHERS
ESC E
ESC z
ESC Y
ESC Z
ESC & p
n
X
..
ESC & s
n
C
27 69
27 122
27 89
27 90
27 38 112
n
88
..
27 38 115
n
67
1B 45
1B 7A
1B 59
1B 5A
1B 26 70
n
58 ..
1B 26 73
n
43
Logical Reset
Autodiagnostics
Code Printing
Disables Code Printing
Transparent Printing Mode
(0 â
n
â 32,767)
Wrap Around
(
n
= 0, enables;
n
=1,
disables)
ESC & k
n
G
ESC & k 0 G
ESC & k 1 G
ESC & k 2 G
ESC & k 3 G
27 38 107
n
71
27 38 107 48 71
27 38 107 49 71
27 38 107 50 71
27 38 107 51 71
1B 26 6B
n
47
1B 26 6B 30 47
1B 26 6B 31 47
1B 26 6B 32 47
1B 26 6B 33 47
Print Line Closure
CR=CR; LF=LF; FF=FF
CR=CR+LF; LF=LF; FF=FF
CR=CR; LF=LF+CR;
FF=FF+CR
CR=CR+LF; LF=LF+CR;
FF=FF+CR
ESC & k
n
F 2738107
n
70 1B 26 6B
n
46 SO/SI enabled for One Line
(
n
= 0, SO/SI enabled for one
line;
n
= 1, standard function
for SO/SI)
(continued)
A-6 Command Codes - PCL III + Command Codes
