OIL BURNER SETUPS
HTL-D and HTLV-D furnaces may be used with the following oil
burners.
Please note: e Beckett AF, NX and Riello 40F oil burners are for
applications using indoor air for combustion only.
Table 3A - Beckett AF Oil Burner Set-Up
Beckett AF Series Oil Burners
(For use with chimney vented units only)
Furnace
Model
Output
BTU/Hr
Burner
Model
Nozzle
Pump
Pressure
Flow Rate Head 1
Static
Plate
HTL-90D 89,200 AF76XN 0.75 / 60°W 100 PSIG 0.75 USGPH F3 2- ¾ in.
HTL-100D 101,100 AF76XN 0.85 / 60°W 100 PSIG 0.85 USGPH F3 2- ¾ in.
HTL-120D 117,600 AF76XN 1.00 / 60°W 100 PSIG 1.00 USGPH F3 2- ¾ in.
HTL-130D 129,300 AF76YB 1.10 / 60°W 100 PSIG 1.10 USGPH F6 2- ¾ in.
HTL-140D 139,400 AF76YB 1.20 / 60°W 100 PSIG 1.20 USGPH F6 2- ¾ in.
Table 3B - Beckett NX Oil Burner Set-Up
Beckett NX Series Oil Burners
(For use with chimney vented units only)
Furnace
Model
Output
BTU/Hr
Burner
Model
Nozzle Pump
Pressure
Flow Rate
HTLV-90DNX 93,000 NX70LHHS 0.65 x 60°W 120 PSIG 0.75 USGPH
HTLV-100DNX 101,100 NX70LHHS 0.75 x 60°W 125 PSIG 0.85 USGPH
HTLV-120DNX 117,600 NX70LHHS 0.90 x 60°W 125 PSIG 1.00 USGPH
HTLV-130DNX 129,300 NX70LB 1.00 x 60°W 120 PSIG 1.10 USGPH
HTLV-140DNX 139,400 NX70LB 1.10 x 60°W 120 PSIG 1.20 USGPH
Table 3C - Riello 40F Series Oil Burner Set-Up
Riello 40F Series Oil Burners
(For use with chimney vented units only)
Furnace
Model
Output
BTU/Hr
Burner
Model
Nozzle Pump
Pressure
Flow Rate
HTL-90DRF
90,300 40F3 0.65 / 60°W 120 PSIG 0.75 USGPH
HTLV-90DRF
HTL-100DRF
101,100 40F3 0.75 / 60°W 125 PSIG 0.85 USGPH
HTLV-100DRF
HTL-115DRF
114,600 40F3 0.85 / 60°W 115 PSIG 0.95 USGPH
HTLV-115DRF
