Olsen HTL-90D - HTL-D & HTLV-D Dimensions

15
Table 7 - General Dimensions (Inches)
Furnace
Model
Cabinet Plenum Openings
Flue
Diameter
Filter Shipping
Weight
(LB.)
Width Depth Height Supply
Return
Type Size
Side Bottom
HTL-D
HTLV-D
22 30-3/4 58
20½ x
20
14 x 22 14 x 22 6 Permanent 16 x 25 x 1 270
HTLD & HTLVD DIMENSIONS
Figure 3 - HTL-D & HTLV-D Dimensions
