PARTS LISTING  HIGHBOY MODELS: HTLD AND HTLVD
Ref.
No.
Part No. DESCRIPTION
1 109007731L Le Side Panel Assembly
2 109007729L Right Side Panel Assembly
3 109007727L Rear Panel
4 29189 Blower Division Assembly
5 26216 Base Panel
6 109007728 Inner Front Panel
7 29122L Blower Access Panel
8 21437L Top Panel
9 26097 Heat Exchanger Assembly
10 27068 Combustion Chamber Retainer Bracket
11 27000WP Replacement Combustion Chamber
12 109007674 Oil Burner Mounting Plate
13 28306 Flue Connector
14 2080175 Pouch Gasket
15 109007733 Air Bae
16 20602 Insulation Retainer
17
240007841 Radiator Clean-out Cover (2 per unit)
240006333 Radiator Clean-out Cover Gasket (2 per unit)
18
29161 Clean-out Gasket Retainer
29163 Clean-out Tube Gasket
19 18020 Filter Frame 16” X 25”
20 5592B2 Filter Frame End Support
21 2180023 Filter 16” X 25” X 1” Permanent
24 29362 Control Box
25
21338L Upper Door Panel
28479 Logo Bezel
28563 Logo Label
26 28841 Limit Disc 60T11 BOF 220°F
27
29388 Fan Timer Control 1158-120 UTEC HTL
240007048 Fan Timer Control 1168-1 ECM UTEC HTLV
28 29364 Wire Harness, Controls Fan Timer
29 29365 Wire Harness, Blower
30 29751 Wire Harness, Fan Timer Board, Transformer
31
240006438 Wire Harness, ECM Control HTLV
240005742 Wire Harness, ECM Supply HTLV
32 240005330 Transformer
33 12240 (6”) Dra Regulator
Ref.
No.
Part No. DESCRIPTION
34a
240007760 Oil Burner Assembly, Beckett AF76XN
29689 Burner Motor 1/7 HP 3450 RPM PSC
29688 Beckett Clean-cut Oil Pump A2EA6520
29522 Solid State Ignitor 10SAY-01
240007858 Oil Primary Combustion Control Genisys
11961 Flame Retention Head F6
14619329 Nozzle, 1.00/60ºW
34b
240007786 Oil Burner Assembly, Beckett AF76YB
29689 Burner Motor 1/7 HP 3450 RPM PSC
29688 Beckett Clean-cut Oil Pump A2EA6520
29522 Solid State Ignitor 10SAY-01
240007858 Oil Primary Combustion Control Genisys
12646 Flame Retention Head F6
14619333 Nozzle, 1.20/60ºW
34c
240007794 Oil Burner Assembly, Beckett NX70LHHS
21839 Burner Motor 1/7 HP 3450 RPM PSC
27593
Beckett Clean-cut Oil Pump A2EA6520
29522 Solid State Ignitor 10SAY-01
240007858 Oil Primary Combustion Control Genisys
240007859 Retention Head Assembly
240006431 Nozzle, 0.65/60ºW
35b
109007722
Blower Assembly Direct Drive 5-Ton PSC Motor
HTL
109007724
Blower Assembly Direct Drive ECM 5-Ton ECM
Motor HTLV
30095 Blower Housing and Wheel, 120-10T DD
102000132 Blower Motor, 3/4 hp, 4-Speed HTL
109007745 Blower Motor, 1hp, ECM Programmed HTLV
17811 Motor Mounting Band – TR6884B
30259
Motor Mount Arms – 12-10 DD Blower (3 per
unit)
27745 Motor Run Capacitor, 20 mfd @ 370 Vac HTL
27761 Capacitor Strap
27733 Blower Slide Rail 2 Per
