52
Chapter 3 Preparation and Inspection
ULTRASONIC BRONCHOFIBERVIDEOSCOPE BF-UC180F
In Steps 6. to 8. below, do not apply excessive force to or
bend the distal end of the endoscope. Instrument damage
may occur.
6. Insert the transducer of the endoscope into the balloon (see Figure 3.31).
Figure 3.31
7. Put the rear band of the balloon into the rear balloon groove of the
endoscope. Then, move the applicator DOWN, away from the distal end of
the endoscope (see Figure 3.32).
Figure 3.32
