Olympus CK40 - SPECIFICATIONS

25
SPECIFICATIONS
Item
Specifications
CK30 CK40
1. Optical system LB optical system (finite-corrected system)
2. Illumination
6 V 30 W HAL high-intensity halogen bulb
Philips 5761
(Average service life: Approx. 100 hrs. when used as directed)
Output rating: 6 V 30 VA
Input rating: 100V area –– 100/110-120 V
0.6 A, 50/60 Hz
200V area –– 220/230-240 V
0.3 A, 50/60 Hz
3. Focusing Vertical movement of revolving nosepiece (stage is fixed)
Coarse/fine adjustment knobs (provided with tension adjustment mechanism)
Stroke (from focal point on stage surface): 7 mm upward and 2 mm downward
4. Revolving nosepiece Quadruple
5. Observation tube
Binocular tube
CH3-BI45
Equivalent of CH3-BI45 incorporated in
microscope body
Tube inclination: 45°
Interpupillary distance adjustment:
48 – 75 mm
Trinocular tube
CH3-TR45
Tube inclination: 45°
Interpupillary distance adjustment:
53 – 72 mm
Tilting binocular tube
CK40-TBI
Tube inclination: 30° – 60°
Interpupillary distance adjustment:
50 – 76 mm
NCWHK10X objective can only be used
6. Eyepiece
NCWHK10X Field of view no. 18
WHK10X Field of view no. 20
WHK15X Field of view no. 12
7. Objectives
For brightfield
EDAch4X
EDAch10X
LWDCDAch20X
N. A. 0.10 W.D. 29.0 mm
N. A. 0.25 W.D. 6.3 mm
N. A. 0.40 W.D. 5.4 mm
For phase contrast
SPlan4XPL-6
DAch10XPL-6
LWDCDAch20XPL-6
LWDCDPlan40XPL-6
LWDCDPlan40XFPL-6
N. A. 0.13 W.D. 15.5 mm
N. A. 0.25 W.D. 7.18 mm
N. A. 0.40 W.D. 5.4 mm
N. A. 0.55 W.D. 2.04 mm with correction
collar
N. A. 0.55 W.D. 2.04 mm
For relief phase
contrast
SPlan4XRP
DAch10XRP
LWDCDAch20XRP
LWDCDPlan40XRP
N. A. 0.13 W.D. 15.5 mm
N. A. 0.25 W.D. 7.18 mm
N. A. 0.40 W.D. 5.4 mm
N. A. 0.55 W.D. 2.04 mm
