Olympus CKX31 - C. DISASSEMBLY AND ASSEMBLY PROCEDURES; 1. CKX31 frame

(A)
(B)
*1
*2
(C)
(D)
*3
*4
(E)
(F)
(G)
*5
*6
*7
(H)
(a)
(b)
(c)
(d)
Adhesive ; OT1026
Screw mounting part :
 Inner screw threads :
Grease ; OT2144
Inner screw threads :
Grease ; OT2144
 Screw it
 to (G).
Change the position
to adjust absolute
optical axis.
Parfocality adjustnent
1. CKX31 frame
(b): Selection
CKX31/CKX41 C. DISASSEMBLY AND ASSEMBLY PROCEDURES
C-1
