Olympus CKX31 - 6. Focusing guide unit

A
A
A
A
(A)
(B)
*1
*2
(C)
(D)
(E)
(F)
*5
*4
(G)
(I)
(H)
(J)
(K)
(L)
(M)
Disassembling nosepiece
*3
(N)
: pushing direction when
assembling the rack.
(See above figure.)
Grease;
OT2010
Arrange the rollers alternately.
Grease;
OT2010
Apply grease to groove and affix
the wire guide(M).
* Arrange the rollers altenately on the upper side
so that they face in same direction to lower side.
Adjustment (guide mounting position)
Working force: standard 0.2 - 0.5N (without play or tightness)
Guide (D)
Grease;
OT2010
Apply grease to
sliding surface
of wire guide.
Fit the protrusions
into the holes of
frame.
Adhesive
tape
Rack
Adhesive;
OT1838
CKX31/CKX41 C. DISASSEMBLY AND ASSEMBLY PROCEDURES
6. Focusing guide unit
Double-sided
C-11
2
