Olympus DM-901 User Manual

1
Setup
11
EN
Setup
Inserting the battery
Before using the voice recorder, remove the battery from the bag and insert it in the battery
compartment.
1
To open the battery cover, slide
the battery cover lock release
lever in the direction of the
arrow.
2
With the label on the back facing
up, align the terminals on the
recorder and the battery, and
then press down in at A and set
the battery into place by pressing
it inward at B.
As shown, set the battery pack so that it tucks
under the protruding section of the recorder.
3
Slide the battery cover until it is
completely closed.
NOTE
• Be sure to firmly close the battery cover
(slide until the battery cover lock clicks).
• Do not close the battery cover if the
battery is not completely inserted.
• Check for any metallic foreign matter or
dust on the terminal of the battery.
• Do not use a battery other than that
specified.

Olympus DM-901 Specifications

General

MP3 bit rates	128 - 256 Kbit/s
WMA bit rates	8 - 32 Kbit/s
Recording modes	High Quality (HQ), Long Play (LP), Pulse-code modulation (PCM)
HQ mode recording time	218 h
Maximum recording time	850 h
Audio formats supported	MP3, PCM, WAV, WMA
HQ mode frequency response	40 - 20000 Hz
SLP mode frequency response	40 - 3000 Hz
Internal memory	4096 MB
Backlight	Yes
Display type	TFT, LCD
Display diagonal	2 \
Display resolution	176 x 220 pixels
Display size (HxV)	31.7 x 39.6 mm
Output power	280 mW
Loudspeaker diameter	20 mm
Interface	USB
FM radio	No
Media types supported	Flash card
Compatible memory cards	SD, SDHC, SDXC
Battery voltage	3.7 V
Battery capacity	1400 mAh
Battery life (max)	29 h
Number of batteries supported	1
Material	Plastic
Product color	Black
Menu languages	CZE, DAN, DEU, DUT, ENG, ESP, FRE, ITA, POL, RUS, SLV
Languages support	DAN, DEU, DUT, ENG, ESP, FRE, ITA, POL, RUS, SLV
Bundled software	Sonority, Audio Management

Weight and Dimensions

Depth	17.9 mm
Width	51 mm
Height	115 mm
Weight	105 g
