DSX1000
XLOB Series 0 to 115 mm
UIS2 Series 0 to 145 mm
Eucentric observation (common objective) 0 to 50 mm
5.5 Rating
5.5.1 Combination with DSX10-UF / DSX10-TF
100-120 V, 220-240 V
1.1/0.54 A
50/60 Hz
5.5.2 Combination with DSX10-CB
100-120 V, 220-240 V
0.93/0.45 A
50/60 Hz
5.6 Application
Supported operating system
Windows 10 64 bit
5.7 Operating environment
Temperature 10 to 35℃
(During Z repeatability measurement, the temperature gradient is within plus or minus 1 °C)
Humidity
30 to 80%
Variation of power-
supply voltage
Rated voltage: ± 10 %
Pollution degree
2 (in accordance with IEC60664)
Installation category
(excess voltage
category)
II (in accordance with IEC60664)
Installation location Flat surface
The product does not overturn even though it is tilted to ±10°.
Operating
environment
・Indoor use
・Altitude: Max. 2000 meters
Temperature: 5 to 40 °C
Relative humidity: 20 to 80% for temperatures up to 31 °C (88 °F) (without condensation)
In case of over 31 °C (88 °F), the relative humidity is decreased linearly through 70% at 34 °C (93
°F), 60% at 37℃ (99 °F), and to 50% at 40℃ (104 °F).
5.8 Measures for safety and environmental law
Regulations for system CE: EN61326 Class A, EN610101-1
19
5.5 Rating5. Specifications
