11
EN
Preparations for shooting
Basic guide
Preparing the battery
2
3
1
BLM-1 Lithium ion
battery
AC wall outlet
BCM-2 Lithium
ion charger
AC cable
Battery lock
It is recommended to set aside a backup battery for prolonged shooting in case the battery
in use drains.
1 Charging the battery
3 Close the battery compartment cover and slide the battery
compartment lock in the direction of E
Press the battery lock to
unlock the battery.
Direction
indicating mark
W
Unloading the
battery
2 Loading the battery
Charging indicator
Red light: Charging in progress
Green light: Charging completed
(Charging time: Approx. 5 hours)
Battery compartment
cover
Battery
compartment lock
Remove the
protection cap from
the battery.
Align the battery with the
arrow.
W
s0018_e_00_0_unified.book Page 11 Tuesday, March 18, 2008 4:08 PM
