Olympus E-M1 MARK II User Manual

130 EN
Menu functions (Custom menus)
4
Viewing camera images on TV
MENU G S [ HDMI]
Use the separately sold cable with the camera to playback recorded images on your
TV. This function is available during shooting. Connect the camera to an HD TV using
an HDMI cable to view high-quality images on a TV screen.
Type A
HDMI cable
(Connect to the HDMI connector on
the TV.)
HDMI connector (type D)
Connect the TV and camera and switch the input source of the TV.
• When an HDMI cable is connected, images are displayed on both the television and the
camera monitor. Information is displayed on the television screen only.
• For details on changing the input source of the TV, refer to the TV’s instruction manual.
• Depending on the TV’s settings, the displayed images and information may become
cropped.
• If the camera is connected via an HDMI cable, you will be able to choose the digital video
signal type. Choose a format that matches the input format selected with the TV.
C4K C4K via HDMI output.
4K Priority is given to 4K HDMI output.
1080p Priority is given to 1080p HDMI output.
720p Priority is given to 720p HDMI output.
480p/576p 480p/576p HDMI output.
• Do not connect the camera to other HDMI output devices. Doing so may damage the
camera.
• HDMI output is not performed while connected via USB to a computer or printer.
• When [Output Mode] is set to [Record Mode] (P. 101), movies are output in the record mode
set for movie. The images cannot be displayed on the connected TV if the TV does not
support the record mode.
• 1080p output will be used in place of [4K] or [C4K] while the camera is being used to take
photographs.
Using the TV remote control
The camera can be operated by a TV remote control when connected to a TV that
supports HDMI control. g [HDMI] (P. 117)
The camera monitor turns off.
• You can operate the camera by following the operation guide displayed on the TV.
• During single-frame playback, you can display or hide the information display by
pressing the “Red” button, and display or hide the index display by pressing the
“Green” button.
• Some televisions may not support all features.

Olympus E-M1 MARK II Specifications

General

Material	Magnesium
Product color	Black
Optical zoom	- x
Lens mount interface	Micro Four Thirds (MFT)
Megapixel	20.4 MP
Camera type	MILC Body
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	4/3 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	8160 x 6120, 5760 x 4320, 10368 x 7776
Viewfinder type	Electronic
Scene modes	Portrait
Image editing	Resizing, Trimming
Photo effects	Black&White, Sepia
White balance	Auto, Flash, Fluorescent, Shade, Sunny, Tungsten, Underwater
Shooting modes	Aperture priority, Auto, Manual, Program, Shutter priority
GPS (satellite)	No
Image processor	TruePic VIII
Self-timer delay	2, 12 s
Languages support	Multi
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 2
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1037000 pixels
Focus adjustment	Auto/Manual
Auto Focus (AF) points	800
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Normal focusing range (tele)	- m
Light metering	Centre-weighted, Spot
ISO sensitivity	200, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	200
Light exposure control	Program AE
Light exposure correction	± 5EV (1/2EV; 1/3EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash guide number	12.9 m
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Battery life (CIPA standard)	440 shots
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVI, H.264, M-JPEG, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Audio system	stereo
Audio formats supported	PCM
Compatible memory cards	SD, SDHC, SDXC
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
Headphone outputs	1
HDMI connector type	Micro
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Cables included	USB
Bundled software	Olympus Viewer

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	498 g
Weight (including battery)	574 g
