Olympus E-M1 MARK II User Manual

80 EN
Playback
3
Slideshow
This function displays images stored on the card one after another.
1
Press the Q button during playback and select
[m].
JPEG
100 %
Rotate
R
Print Order
Copy
Erase
Back Set
2
Adjust settings.
Start
Start the slideshow. Images are displayed in order, starting with the
current picture.
BGM
Set [Party Time] or [Off].
Slide
Set the type of data to be played back.
Slide Interval
Choose the length of time each slide is displayed from 2 to 10 seconds.
Movie Interval
Select [Full] to play back full length of each movie clip in the slideshow or
[Short] to play back only the opening portion of each movie clip.
3
Select [Start] and press the Q button.
• The slideshow will start.
• Press the Q button to stop the slideshow.
Volume
Volume can be adjusted by pressing F or G during single-
frame and movie playback.
00:00:02/00:00:14
100 %
Slideshow volume
Press FG during the slideshow to adjust the overall volume of the camera speaker.
Press HI while the volume adjustment indicator is displayed to adjust the balance
between the sound recorded with the image or movie and background music.

Olympus E-M1 MARK II Specifications

General

Material	Magnesium
Product color	Black
Optical zoom	- x
Lens mount interface	Micro Four Thirds (MFT)
Megapixel	20.4 MP
Camera type	MILC Body
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	4/3 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	8160 x 6120, 5760 x 4320, 10368 x 7776
Viewfinder type	Electronic
Scene modes	Portrait
Image editing	Resizing, Trimming
Photo effects	Black&White, Sepia
White balance	Auto, Flash, Fluorescent, Shade, Sunny, Tungsten, Underwater
Shooting modes	Aperture priority, Auto, Manual, Program, Shutter priority
GPS (satellite)	No
Image processor	TruePic VIII
Self-timer delay	2, 12 s
Languages support	Multi
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 2
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1037000 pixels
Focus adjustment	Auto/Manual
Auto Focus (AF) points	800
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Normal focusing range (tele)	- m
Light metering	Centre-weighted, Spot
ISO sensitivity	200, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	200
Light exposure control	Program AE
Light exposure correction	± 5EV (1/2EV; 1/3EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash guide number	12.9 m
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Battery life (CIPA standard)	440 shots
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVI, H.264, M-JPEG, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Audio system	stereo
Audio formats supported	PCM
Compatible memory cards	SD, SDHC, SDXC
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
Headphone outputs	1
HDMI connector type	Micro
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Cables included	USB
Bundled software	Olympus Viewer

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	498 g
Weight (including battery)	574 g
