Olympus E-M1 MARK II User Manual

152 EN
Cautions
7
External fl ash units designated for use with this camera
With this camera, you can use one of the separately sold external fl ash units to
achieve a fl ash suited to your needs. The external fl ashes communicate with the
camera, allowing you to control the camera’s fl ash modes with various available fl ash
control modes, such as TTL-AUTO and Super FP fl ash. An external fl ash unit specifi ed
for use with this camera can be mounted on the camera by attaching it to the camera’s
hot shoe. You can also attach the fl ash to the fl ash bracket on the camera using the
bracket cable (optional). Refer to the documentation provided with the external fl ash
units as well.
The upper limit of the shutter speed is 1/250 sec. when using a fl ash.
* The sync speed for silent mode and focus bracketing (P. 94) is 1/50 second. The sync
speed at ISO sensitivities of 8000 and above and during ISO bracketing (P. 94) is
1/20 second.
Functions available with external fl ash units
Optional fl ash Flash control mode GN (Guide number) (ISO100) RC mode
FL-900R
TTL-AUTO, AUTO,
MANUAL, FP TTL
AUTO, FP MANUAL,
MULTI, RC, SL AUTO,
SL MANUAL
GN58 (200 mm*
1
)

FL-600R
TTL-AUTO, AUTO,
MANUAL, FP TTL
AUTO, FP MANUAL
GN36 (85 mm*
1
) GN20 (24 mm*
1
)

FL-300R TTL-AUTO, MANUAL GN20 (28 mm*
1
)

FL-14
TTL-AUTO, AUTO,
MANUAL
GN14 (28 mm*
1
)–
STF-8 TTL-AUTO, MANUAL GN8.5

*1 The focal length of the lens that can be used (Calculated based on 35 mm fi lm camera).

Olympus E-M1 MARK II Specifications

General

Material	Magnesium
Product color	Black
Optical zoom	- x
Lens mount interface	Micro Four Thirds (MFT)
Megapixel	20.4 MP
Camera type	MILC Body
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	4/3 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	8160 x 6120, 5760 x 4320, 10368 x 7776
Viewfinder type	Electronic
Scene modes	Portrait
Image editing	Resizing, Trimming
Photo effects	Black&White, Sepia
White balance	Auto, Flash, Fluorescent, Shade, Sunny, Tungsten, Underwater
Shooting modes	Aperture priority, Auto, Manual, Program, Shutter priority
GPS (satellite)	No
Image processor	TruePic VIII
Self-timer delay	2, 12 s
Languages support	Multi
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 2
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1037000 pixels
Focus adjustment	Auto/Manual
Auto Focus (AF) points	800
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Normal focusing range (tele)	- m
Light metering	Centre-weighted, Spot
ISO sensitivity	200, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	200
Light exposure control	Program AE
Light exposure correction	± 5EV (1/2EV; 1/3EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash guide number	12.9 m
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Battery life (CIPA standard)	440 shots
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVI, H.264, M-JPEG, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Audio system	stereo
Audio formats supported	PCM
Compatible memory cards	SD, SDHC, SDXC
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
Headphone outputs	1
HDMI connector type	Micro
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Cables included	USB
Bundled software	Olympus Viewer

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	498 g
Weight (including battery)	574 g
