Olympus IX51 - Specifications; Component Specifications Overview

52
Light path selection S8F-3: Binocular 100% or Binocular 20%/Side port 80%
(with shockless mechanism)
S1F-3: Binocular 100%/Side port 100%
Intermediate magnification changer: 1X 1.6X*
Side port magnification: 1X (perfect aberration correction)
Focusing up/down stroke: 9 mm (7 mm above focusing position plus 2 mm
below focusing position)
6-position revolving nosepiece (DIC slider attachable)
SPECIFICATIONS
Module Specification
Microscope
Frames
IX71S8F-3
IX71S1F-3
IX51S8F-3
IX51S1F-3
*The IX51 series does not use an
intermediate magnification
changer.
Illumination
Columns
IX2-ILL100
Column for installing the lamp housing for 100 W halogen bulb, precentered.
With 30° tilting mechanism.
Variety of condenser can be attached.
IX2-ILL30 Column for installing the U-LS30-3 lamp socket for 6 V, 30 W halogen bulb.
Precentered.
Provided with a condenser (NA 0.3, WD 72 mm)
Observation
Tube
U-BI90CT Binocular tube with 45° tilting angle. Built-in CT, diopter adjustment on one
eyepiece possible. Eye point switchable in 2 steps of 400 and 430 mm.
U-BI90 Binocular tube with 45° tilting angle. Diopter adjustment on one eyepiece
possible. Eye point switchable in 2 steps of 400 and 430 mm.
U-TBI90 Binocular tube with 35° to 85° tilting angle. Diopter adjustment on one eyepiece
possible. Eye point 406 to 471 mm.
U-TR30H-2 Trinocular tube with 30° tilting angle. Can be installed by means of the IX-ATU
intermediate tube. Eye point 434 mm.
U-MO Monocular tune with 45° tilting angle. 10X eyepiece fixed.
Condensers IX2-LWUCDA2, IX2-LWUCD NA 0.55, WD 27 mm. Motorized turret with 6 positions or manual turret with 5
positions.
IX-ULWCD NA 0.3, WD 73 mm. Manual turret with 4 positions.
U-UCD8 Dry: NA 0.9, WD 1.5 mm.
Oil immersed: NA 1.4, WD 0.6 mm.
Stages IX2-SFR Coaxial flexible knobs on the bottom right position. Movement range 50 mm
(X) x 50 mm (Y). Center plate diameter 110 mm.
IX-SVL2 Coaxial knobs on the bottom left position. Movement range 50 mm (X) x
43 mm (Y). Center plate diameter 110 mm.
IX2-SP, IX-MVR Size 232 mm (X) x 240 mm (Y). Coaxial flexible knobs on the bottom side.
Movement range 130 mm (X) x 85 mm (Y). Center plate diameter 110 mm.
IX2-KSP, CK40-MVR Size 160 mm (X) x 240 mm (Y). Coaxial knobs on the bottom. Movement range
120 mm (X) x 78 mm (Y). Center plate diameter 110 mm.
Eyepieces WHN10X
Field number 22.
WHN10X-H Field number 22, with diopter adjustment helicoid.
35WHN10X Field number 22, with 35 mm film photo mask and diopter adjustment helicoid.
