3.4 Connection of foot switch hanger
23
MAJ-2301 INSTRUCTION MANUAL
Ch.3
Be sure to use the provided Allen screwdriver (3 mm width across flats) and lock
screws (M4 × 12 mm) (× 2) for work. Otherwise, insufficient locking may cause the
foot switch hanger to rattle or the foot switch to unhook from the switch hanger and
drop during use and cause equipment damage.
4 Confirm that the foot switch hanger is fixed firmly to the movement handle without
rattling.
