Olympus VS120 - Managing Acquired Image Save Locations

Acquiring Images / Changing the Save Location for Acquired Images
30
Page
1-5 Changing the Save Location for Acquired Images
Acquired images are automatically saved.
If using a database, you can set the image save location to either the hard disk drive (default) or the database.
Select either [To Disk] or [To Database] from the
[Automatic Save] options on the screen for
selecting the objective lens.
Click the button under [Location], and set
thesave location for the image in the screen
displayed.
This operation can be used in Quick Batch Mode and Expert Batch Mode.
In Quick, Expert, or Virtual Z mode, click and
setthe save location in the window displayed.
TIP
