Omega DP25B-E - Back of the Meter; Connector Label (AC-Powered and DC-Powered Detail)

2
About The Meter
8
2.5 BACK OF THE METER
Figure 2-2 shows the label describing the connectors on the back of the meter. Table 2-2
on the following page gives a brief description of each connector at the back of the meter.
Figure 2-3. Connector Label (AC-Powered and DC-Powered Detail)
