SECTION 5. DISPLAY MESSAGES
Table 5-1. Display Messages
MESSAGE DESCRIPTION
PROC Process Meter
RST Hard (Power On) Reset
INPT Input Type
DEC.P Decimal Point
RD.S.O Reading Scale and Offset
RD.CF Reading Configuration
COLR Display Color
S1.CF Setpoint 1 Configuration
S2.CF Setpoint 2 Configuration
S1.DB Setpoint 1 Deadband
S2.DB Setpoint 2 Deadband
P.BND Proportional Band
M.RST Manual Reset
ER4 Manual Reset Error
OT.CF Output Configuration
OT.S.O Output Scale and Offset
LK.CF Lock Out Configuration
BRIT Display Brightness
+OL + Overload Signal
-OL - Overload Signal
RS.OF Resolution Overflow
+999 Value Overflow in Setpoint/Menu & Peak Routines
-1999 Value Overflow in Setpoint/Menu & Peak Routines
ER1 2 Coordinate Format Programming Error
PEAK Peak Value
PK.RS Peak Reset
T.RS Tare Reset
SP.RS Reset Latched Alarms
SP1 Setpoint 1 Value
SP2 Setpoint 2 Value
R.OV.S Resolution Over Scale
V.-8.8 Firmware Version (where
8
is 0 ~ 9)
RUN Operating Mode
