4
Configuring The Meter
28
4.3.2 Scaling Without Known Loads (Continued)
3. Determine IN1 & IN!2 input range and resolution. The example selects the 0 to
10 V range and 10 uV resolution (R.2=4 ).
Example: IN1 = (1 Volt) x (1000 cts/v) x (1.000) = 1000
IN!2 = (5 Volt) x (1000 cts/v) x (1.000) = 5000
RD1 = 0000
RD!2 = 2000
4. Press MENU button until the meter shows RD.S.O .
5. Press the
∂∂
TARE button. The meter shows IN1 .
6. Press the
∂∂
TARE button again, the meter shows the last Input 1 value, with the
fourth digit flashing.
7. Press the
ßß
MAX button to change the value of your digits.
8. Press the
∂∂
TARE button to scroll horizontally to the next digit.
9. Press the MENU button to store this value. The meter shows RD1 .
10. Press the ∂TARE button. The meter shows the last value for read 1.
Repeat steps 7, 8 and 9 until RD1 , IN!2 and RD!2 have been displayed, verified,
changed (if necessary) and stored.
4.4 USING READING CONFIGURATION RD.CF
Refer to Table 6-1 for a summary list of menu configuration.
You may use Reading Configuration RD.CF to configure your meter for the following:
• To enable or disable the front panel tare
• To set the input resolution of your meter
• To display the filtered/unfiltered signal input value
