55
Specifications
8
SECTION 8. SPECIFICATIONS (Continued)
Table 8-1. COLOR CHART FOR DC POWER
COLOR HIGH BRIGHTNESS MEDIUM & LOW BRIGHTNESS
RED Sensor Excitation: Any combination of Sensor Excitation
24 V @ 25 mA, and Analog Output
12 V, 10 V, 5 V @ 35 mA Max 24 V @ 25 mA,
Analog Output: 12 V @ 35 mA Max
Non-Isolated option only 10 V @ 35 mA Max
5 V @ 35 mA Max
GREEN
Analog Output:
Non-Isolated options or
Isolated Analog option
AMBER
W
arning:
• Do not use Internal Excitation.
Use External Excitation.
•
Do not use Isolated Analog Output.
Use Non-Isolated Analog Ouput.
HIGH/LOW Brightness and AMBER are only available on Version “B” meters.
Standard display meters are MEDIUM Brightness.
