6
Menu Configuration Displays
48
SECTION 6. MENU CONFIGURATION DISPLAYS (Continued)
Table 6-1. Menu Configuration Displays (Continued)
(Defaults in Bold and Italics)
MENU ∂TARE ßMAX
Press to scroll to the Press to change the value of the
Setpoint 1 Deadband
next digit to the right flashing digit
S1.DB
Press to scroll to the Press to change the value of the
Setpoint 2 Deadband
next digit to the right flashing digit
S2.DB
0.1 = 0.1=E (Analog output is enabled)
Output Configuration
0.1=D (Analog output is disabled)
OT.CF
0.2 = 0.2=C (Analog output is current)
0.2=V (Analog output is voltage)
0.3 = 0.3=A (Regular analog output)
0.3=P (Proportional analog output)*
0.4 = 0.4=D (Proportional analog is direct acting)
shown if menu 0.3=P 0.4=R (Proportional analog is reverse acting)
0.5 = 0.5=F (Analog output is 0-10 Vdc)
shown if menu 0.2=V 0.5=H (Analog output is 0-5 Vdc)
* If you select 0.2V and 0.3=P , you may select your analog
output to be
0-10 V or 0-5 V by accessing submenu 0.5=F
or 0.5=H
.
*I
f 0.3=P , you may select your proportional output analog to be:
• Direct Acting 0.4=D : 4-20 mA, 0-5 V, 0-10 V
• Reverse Acting 0.4=R : 20-4 mA, 5 V-0 V, 10 V-0 V
