Section 5.18 - Function F - Serial Configuration
Function F sets up the serial port of the device. The default serial settings are RS485,
115.2k baud no Parity.
Increment the flashing digit on the display
Selects the next digit of the VALUE display, causing it to flash.
Stores the current VALUE display as the Serial configuration and
returns to the Function Select mode. This button will have no ef-
fect if the current VALUE is does not match a valid configuration.
Series Navigation
5
Digit 1 Digit 2 Digit 3 Digit 4 (LSD)
Signaling Type Baud Rate Parity
0 RS485 0 4800 0 None 0 Reserved
1 RS232 1 9600 1 Odd
2 19200 2 Even
3 38400
4 57600
5 115200
Table 7 - Serial Port Configuration
