Omega DP606A User Manual

Modbus Register Assignments
7
Index Mnemonic Type Access Description
0x1d7c 47548 Zone 1 RTD offset F RW Offset Ohm for Zone 1
0x1d7e 47550 Zone 2 RTD offset F RW Offset Ohm for Zone 2
0x1d80 47552 Zone 3 RTD offset F RW Offset Ohm for Zone 3
0x1d82 47554 Zone 4 RTD offset F RW Offset Ohm for Zone 4
0x1d84 47556 Zone 5 RTD offset F RW Offset Ohm for Zone 5
0x1d86 47558 Zone 6 RTD offset F RW Offset Ohm for Zone 6
0x1d88 47560 Zone 7 RTD offset F RW Offset Ohm for Zone 7
0x1d8a 47562 Zone 8 RTD offset F RW Offset Ohm for Zone 8
0x1d8c 47564 Zone 9 RTD offset F RW Offset Ohm for Zone 9
0x1d8e 47566 Zone 10 RTD offset F RW Offset Ohm for Zone 10
0x1d90 47568 Zone 11 RTD offset F RW Offset Ohm for Zone 11
0x1d92 47570 Zone 12 RTD offset F RW Offset Ohm for Zone 12
Section 7.5 - User Calibration
Table 15 - User Calibration
Section 7.6 - Enumerated Values
The following define the Enumerated values.
Section 7.7 - Sensor Type
Sensor Type
0 THERMOCOUPLE Thermocouple input
1 RTD 2 WIRE Two wire RTD input
2 RTD 3 WIRE Three wire RTD input
3 CURRENT Process Current input
4 VOLTAGE Process Voltage input
Section 7.8 - RTD Type
RTD Type
0 PT_100 Platinum Pt100 RTD
1 NI_90 Nickel Ni90 RTD
2 CU_10 Copper Cu10 RTD
3 NI_120 Nickel Ni120 RTD
