Omnia 6 Use and Installation Guide – Version 1.00a
7
7
Powering Up
When the Omnia-6fm is first turned on, an operating system start up screen is displayed on the left-hand display.
Under normal conditions, it should appear as:
If the Network Configuration has been changed from the factory defaults, a second screen will appear when the unit
does a warm boot to load the network parameters:
After approximately ten seconds, audio will be present from the analog, composite and headphone outputs. The
AES/EBU output becomes usable at this time however, full initialization of the port is not complete for several more
seconds. After 25 to 30 seconds, the Meter and Main Menu displays will appear on the left and right LCD screens
respectively. At this point, the Omnia 6 is fully operational.
