LVS-7500 External System Operations Manual Page 103 of 129
Appendix A: LVS7500.INI File
The LVS-7500 uses the LVS7500.ini file to configure variable/default values when the program loads. The file is
located in the following directory:
• For new installations of software version 5.6.3 on Windows® 7 Professional and Windows® 8.
1
Professio
nal operating systems: C:\LvsData\LVS 7500
• For systems that are upgrading from a previous software version to version 5.6.3 or highe
r:
o Windo
ws® XP: C:\Program Files\Label Vision Systems\LVS7500\LVS7500.ini
o Windows® 7: C:\Users\[User Login Name]\ AppData\Roaming\Label Vision System
s\LVS
7500\LVS7
50
0.ini
Below is a sample LVS7500.ini file with descriptions:
SystemConfiguration Settings:
The SystemConfiguration settings are not user configurable and should not be altered unless requested by an
Omron Microscan representative.
• CameraPort is designated as 0 for the LVS-7500 software.
• DistanceMethod=0 – LVS-7500 shows Encoder Triggers; DistanceMethod=1 – Encoder distance is shown
in inches.
• EncoderPort is determined by the encoder board’s serial port in Device Manager.
• MaxSpeed is determined by the camera’s top speed
• LinesPerInch is the product of dividing the encoder’s pulses per revolution by the circumference of the
encoder wheel. This number is used to correctly gauge label repeat.
• PageBreaks are used to let the system know if there are expected non-uniformities of label repeats. 0 =
none expected, 1=expected. If the system expects these repeats then it will not log those as errors once
seen. This is dangerous as the system in this mode can be fooled by a missing label. It can let a missing
label go by and never call out an error.
• RIMSBarcodePlacement is an offset for the barcode placement in a LVS7500 RIMS system from the
camera viewing point.
• ShowPrintBarcode is the press Identifier for multiple presses in a LVS7500 RIMS system
[SystemConfiguration]
CameraPort=0
DistanceMethod=1
EncoderPort=-1
MaxSpeed=5
LinesPerInch=400
PageBreaks=0
RimsBarcodePlacement=
ShowPrintBarcode=0
Alarm Matrix:
Default settings for the Alarm Matrix. These settings are entered by the Installation Technician at the time of
system installation.
• UseAcknowledgementIO=1 – When this setting is set to 1, and UsePassFailMeth
od=1, the Alarm Matrix
Pass/F
ail view is displayed along with the “Ack Input” and “Ack Output” column
s.
•
UsePassFailMethod indicates how the
Alarm Matrix is displayed.
o
UsePassFailMethod=0 (default) – Displays the Alarm Matrix in the “Error Condition View,” whic
h
displ
ays error-specific I/O informatio
n.
