Error Code Definitions
Error Code Definition
N/A Good Read When the system is triggered, the camera takes a picture of the label.
The system reads all sectors within the image and compares to the
associated sector data in the data file. All sectors match. The system
logs to the report the data read from each sector with no error codes
attached.
N/A Stop Motion This output is used as a special I/O that is sent at a fixed distance
beyond the located error. It is used for machines that have accurate
error placement capabilities.
N/A Grade Warning
This output is used most commonly for the yellow light. It is triggered in
conjunction with !QU (quality errors). When something falls into the
quality warning zone this output is activated.
!BG Background
This is a blemish error. The background is defined in the blemish sector
setup. This means it is in the background portion of the sector.
!DC Die Cut
Die Cut checks the print as compared to the outside edge of the label
to track how much it moves.
!DE Delta E Represents a Delta E error which occurs when the color measured
deviates too far from the predetermined Golden color threshold. Delta
E settings are defined in the “Sector Type 8: Delta E” section.
!DU Duplicate
A !DU appears when the character string has been read before in the
job that you are running. The Check for Duplicates option in the
Matching screen will enable this error.
!FG Foreground
This is a blemish error. The foreground (!FG) is defined in the blemish
sector setup. This means it is in the foreground portion of the sector.
!GP Gap
When the system is triggered, the camera takes a picture of the label.
The system does not read any of the sectors within that image. The
system does not continue to increment the next expected record within
the datafile. The system logs to the report the !GP error code to the
associated data.
!MX Matrix Matrix searches the areas between labels for unstripped waste.
MM! Mismatch
When the system is triggered, the camera takes a picture of the label.
The system reads all sectors within the image and compares to the
associated Job/Sector data in the datafile. One or more sectors do not
match to what the Job/Sector settings dictate that it should be. The
system logs to the report the data read from each sector attaching the
MM! error code to the associated sector's data.
Note: Mismatch only applies when comparing the data to a match
source. If running a Sequential type match, then a Mismatch error will
be reported as a Sequence error.
!NA Not Assessed
The incoming data is not being assessed due to a separate error.
