Omron 1S Series Practices Guide

28
7-4-3 Copying Data Types
In the NA project in the sample project file, the data types of the global variables required to
interface with the NJ/NX and to control the NA pages are declared. Copy all the information
to the user project.
7-4-4 Copying Global Variables
In the NA projects in the sample project file, the global variables required to interface with
the NJ/NX and to control the NA pages are declared. Copy this information to the user
project. Since the variables mapped in the previous step have already been registered as
the NA global variables, copy all the variables in the NA project in the sample project file that
are not mapped.
7-4-5 Copying Pages
Copy all the pages included in the NA projects in the sample project file to the user project.
When copying the page, make sure that the page name and index are not used for existing
pages. When the name and index are already used, modify them.
Additional Information
If a dialog box to confirm whether to overwrite resources appears when you copy a
page, do not overwrite. If you select to overwrite, the data already created in the user
project may be affected.
7-4-6 Copying Resources
The resources (e.g., text data) used in the pages included in the NA project in the sample
project file are automatically merged when the pages are merged.
If there are any resources that were not copied, copy them manually.

Omron 1S Series Specifications

General

Safety Function	STO (Safe Torque Off)
Motor Capacity	50 W to 15 kW
Output Power	50 W to 15 kW
Communication Interface	EtherCAT, MECHATROLINK-II/III
Feedback	Incremental Encoder
Operating Temperature	0 to +55°C
Protection Features	Overcurrent, Overvoltage
Ambient Humidity	20% to 90% RH (non-condensing)
Installation	Panel Mount
Weight	Varies by model
Storage Temperature	-20 to 85°C
