Omron 1S Series User Manual

12AC Servomotors/Servo Drives 1S-series Instruction Manual
 400-VAC Input Model: R88D-1SANF-ECT
Use a neutral grounded 400 VAC 3-phase power supply for the 400 VAC input models.
External dimensions
(W×H×D)
mm 85×180×215
Item Unit
Model (R88D-1SAN)
10H-ECT 15H-ECT 20H-ECT 30H-ECT
Rated voltage VAC
200 to 240 (170 to 252)
*1
*1. The values outside parentheses indicate the rated value, and the values inside parentheses indicate
the range of acceptable variation.
3-phase
Single-
phase/3-
phase
3-phase
Power supply frequency Hz 50/60 (47.5 to 63)
*1
Rated input
current
Single-phase Arms --- 15.7 --- ---
3-phase Arms 5.8 9.0 13.0 15.9
Rated output W 1k 1.5k 2k 3k
Rated output current (FLA) Arms 7.7 9.7 16.2 22.3
Weight kg 2.6 4.2 4.2 4.2
External dimensions
(W×H×D)
mm 85×180×215 110×180×225
Item Unit
Model (R88D-1SAN)
10F-ECT 15F-ECT 20F-ECT 30F-ECT
Rated voltage VAC
380 to 480 (323 to 504)
*1
*1. The values outside parentheses indicate the rated value, and the values inside parentheses indicate
the range of acceptable variation.
3-phase
Power supply frequency Hz 50/60 (47.5 to 63)
*1
Rated input current Arms 3.1 4.3 6.5 8.4
Rated output W 1k 1.5k 2k 3k
Rated output current (FLA) Arms 4.1 4.7 7.8 11.3
Weight kg 4.2 4.2 4.2 4.2
External dimensions
(W×H×D)
mm 110×180×225
Item Unit
Model (R88D-1SAN)
02H-ECT 04H-ECT 08H-ECT

Omron 1S Series Specifications

General

Safety Function	STO (Safe Torque Off)
Motor Capacity	50 W to 15 kW
Output Power	50 W to 15 kW
Communication Interface	EtherCAT, MECHATROLINK-II/III
Feedback	Incremental Encoder
Operating Temperature	0 to +55°C
Protection Features	Overcurrent, Overvoltage
Ambient Humidity	20% to 90% RH (non-condensing)
Installation	Panel Mount
Weight	Varies by model
Storage Temperature	-20 to 85°C
