4AC Servomotors/Servo Drives 1S-series Instruction Manual
Warning and Caution
Transporting and Unpacking
Installation, Wiring and Maintenance
The filled circle symbol indicates operations that you must do.
The specific operation is shown in the circle and explained in
text.
This example indicates a requirement for the ground.
WARNING
Do not damage, pull, or put excessive stress or heavy objects on
the cables.
Doing so may cause electric shock, malfunction, or burning.
WARNING
Install the Servo Drive and Servomotor before wiring.
Not doing so may cause electric shock.
Be sure to ground the 200-VAC input model Servo Drive and Ser-
vomotor to 100 Ω or less, and the 400-VAC input model to 10 Ω or
less.
Not doing so may cause electric shock.
Do not remove the front cover, terminal covers, cables, or periph-
eral equipment while the power is supplied.
Doing so may cause electric shock.
Before carrying out wiring or inspection, turn OFF the main circuit
power and wait for at least the following specific time.
Not doing so may cause electric shock or burning.
10 minutes: R88D-1SAN10F-ECT, R88D-1SAN15F-ECT,
R88D-1SAN20F-ECT, R88D-1SAN30F-ECT
20 minutes: R88D-1SAN02H-ECT, R88D-1SAN04H-ECT,
R88D-1SAN08H-ECT, R88D-1SAN10H-ECT,
R88D-1SAN15H-ECT, R88D-1SAN20H-ECT,
R88D-1SAN30H-ECT
Do not damage, pull, or put excessive stress or heavy objects on
the cables.
Doing so may cause electric shock, malfunction, or burning.
Use appropriate tools to wire terminals and connectors.
Check that there is no short-circuit before use.
Not doing so may cause electric shock.
