5 AC Servomotors/Servo Drives 1S-series Instruction Manual
Operation Check
Usage
Connect the frame ground wire in the integrated cable securely to
the or FG of the Servo Drive.
Not doing so may cause electric shock.
Provide safety measures, such as a fuse, to protect against short
circuiting of external wiring and failure of the Servo Drive.
Not doing so may cause a fire.
Install the Servomotor, Servo Drive, and peripheral equipment on
non-flammable materials such as metals.
Not doing so may cause a fire.
Keep conductive or flammable foreign objects such as screws,
metal pieces, and oil out of the Servo Drive and connectors. Pay
particular attention to the connector on the top part of Servo Drive.
Not doing so may cause a fire or electric shock.
Design the configuration to cut off the main circuit power supply
when the ERR signal (normally close contact) of the control output
function is output (open).
Do not bundle the integrated cables.
Not doing so may cause fire.
Lock the integrated cable and extension cable connectors.
Not doing so may cause fire.
WARNING
Use the Servomotor, Servo Drive and integrated cable in a speci-
fied combination.
Not doing so may cause fire or equipment damage.
WARNING
Do not enter the operating area during operation.
Doing so may cause injury.
