39 AC Servomotors/Servo Drives 1S-series Instruction Manual
 R88D-1SAN15H-ECT/R88D-1SAN20H-ECT/R88D-1SAN30H-ECT/
R88D-1SANF-ECT
Servo Drive model Weight
R88D-1SAN15H-ECT 4.2 kg
R88D-1SAN20H-ECT 4.2 kg
R88D-1SAN30H-ECT 4.2 kg
R88D-1SAN10F-ECT 4.2 kg
R88D-1SAN15F-ECT 4.2 kg
R88D-1SAN20F-ECT 4.2 kg
R88D-1SAN30F-ECT 4.2 kg
M4
110 50
60
80
180
180
225
2-M4
169.5±0.5
49±0.5
98±0.5
(180)
M4
6
6
5.5
5.2
3-M4
110
External
dimensions
Mounting
dimensions
Air
intake
Air
outlet
