Omron 3G3M1-STD User Manual

15
Trefas 200-V Klass
HHD: Heavy load, HND: Light load
3 fas 3G3M1-A2
001
002
004
007
015
022
037
055
075
110
150
185
Maximal
tillämplig
motorkapacitet
kW
HHD
0.1
0.2
0.4
0.75
1.5
2.2
3.7
5.5
7.5
11
15
18.5
HND
0.2
0.4
0.75
1.1
2.2
3
5.5
7.5
11
15
18.5
22
HP
HHD
1/8
1/4
1/2
1
2
3
5
7 1/2
10
15
20
25
HND
1/4
1/2
1
1 1/2
3
4
7 1/2
10
15
20
25
30
Nominell
uteffekt [kVA]
200 V
HHD
0.3
0.6
1
1.7
2.8
3.8
6.1
8.7
11
16
21
26
HND
0.5
0.7
1.2
2.1
3.3
4.2
6.8
10
14
19
24
30
240 V
HHD
0.4
0.7
1.2
2.1
3.3
4.6
7.3
10
14
20
25
32
HND
0.5
0.8
1.5
2.5
4.0
5.0
8.1
12
17
23
29
37
Ingångsspänning /frekvens
3 fas: 200V -15% ~ 240V+10%, 50/60Hz +/- 5%
Ingångsström [A]
HHD
1.1
1.8
3.1
5.3
9.5
13.2
22.2
31.5
42.7
60.7
80
97
HND
1.8
2.6
4.9
6.7
12.8
17.9
28.5
42.7
60.7
80
97
112
Utgångsspänning [V]
3 fas: 200-240 V (med AVR (Automatisk Volt Regulator))
Utgångsström [A]
HHD
1
1.6
3
5
8
11
17.5
25
33
47
60
76
HND
1.3
2
3.5
6
9.6
12
19.6
30
40
56
69
88
Minimum utgående frekvens
0.0Hz
Maximum utgående frekvens
590Hz
Kylningsmetod
Självkylande
1 Fläkt
2 Fläktar
Förlust vid 0 % belastning av
märkströmmen [W]
10
10
10
10
12
12
12
14
14
19
19
--
Förlust vid 100 % belastning av
märkströmmen [W]
12
22
30
48
79
104
154
229
313
458
625
--
3G3M1 STD Standard gemensamma specifikationer
Funktionalitet
Startmoment
• 150% min. / Rated speed of 10%
V/f control (IM motor)
V/f control (slip compensation)
V/f control with sensor (IM motor)
• 200% min./0.5 Hz
Sensorless vector control (dynamic vector control)
V/f control with sensor (auto torque boost)
Sensorless vector control
• 200% min./0.0 Hz (0 Hz torque control)
Vector control with sensor (IM motor)
Vector control with magnetic pole position sensor (PM motor)
To obtain 200% starting torque at low speed, consider raising the capacity of the
inverter to the next higher capacity.
• 200% min. / Rated speed of 10%
Magnetic pole position sensorless vector control (PM motor)
To obtain these starting torques at low speed, the capacity of the inverter and motor
must be taken into consideration.
The maximum torque that can be used is limited when the current capacity matched
to the mode is exceeded. Current capacity of 200% in HHD mode, 150% in HD mode, and
120% in HND and ND modes
Överbelastning (1 minut)
Heavy load rating (HHD): 150% av den nominella utgångsströmmen i 60 sekunder eller
200% av den nominella utgångsströmmen i 0.5 sekunder.
Heavy load rating (HD): 150% av den nominella utgångsströmmen i 60 sekunder.
Light load rating (HND/ND): 120% av den nominella utgångsströmmen i 60 sekunder.
Val av regleringsmetod
V/f control (no slip compensation), Dynamic torque vector control, V/f control (with slip
compensation), V/f control with speed sensor, Dynamic torque vector control with speed
sensor, Sensorless vector control, Vector control with speed sensor, Torque control (vector
control with speed sensor)
Digital ingång
7x (DI1 till DI7, programmerbara ingångar)
Digital utgång
2x (DO1 till DO2, programmerbara transistorutgångar)
1x (SPDT-kontakt (ROA, ROB, ROC), programmerbar reläutgång)
Pulsingång
1x (A, B, Z faser kan matas in, max. 32 kHz, 5 till 24 VDC)
