3 Operation Procedure for DriveProgramming
DriveProgramming User’s Manual (I622-E1)
3-2 Parameters Related to DriveProgramming
3
3-2 Parameters Related to DriveProgramming
This section describes the inverter parameters that are related to the DriveProgramming.
To initialize the DriveProgramming program downloaded to the inverter, select 04 (Trip history + param-
eters + DriveProgramming) for the Initialize Mode selection (Ub-01), and execute initialization by Initial-
ize Enable (Ub-05).
Use FW (forward) and RV (reverse) variables to control RUN commands through the DriveProgramming
program. Be sure to set the RUN Command Selection (A002/A202) to 01 (Control circuit terminal block)
when you use FW or RV variable.
Initializing Programs
Parame-
ter No.
Function name Data Description
Ub-01 Initialize Mode
selection
00: Disabled Select 04 to initialize the DriveProgram-
ming program as well.
01: Trip history
02: Parameter initialization
03: Trip history + parameters
04: Trip history + parameters +
DriveProgramming
05: Other than terminal function
06: Other than communication
function
07: Other than terminal&commu-
nication functions
08: Only DriveProgramming
RUN Command Selection Setting
Parameter
No.
Function name Data Description
AA111
/AA211
Run-command input
source selection
00: [FW]/[RV] terminal Set operation commands to 00 (FW/RV ter-
minal) when the inverter starts/stops by vari-
ables FW/RV.
01: 3 wire
02: RUN key on operator LCD
Operator
03: RS485
04: Option 1
05: Option 2
06: Option 3
CA-01 to
CA-11
Input terminal 1 to 9,
A and B
99: PRG
Starting of EzSQ program
When the EzSQ function enable (UE-02) is
set to 01 ([PRG] terminal: Start/stop via the
input PRG terminal), the program is started
via input terminal with this setting.
