Instruction OFF execution time (μs)ON execution time (μs)ConditionsInstruction
C200HEC200HGC200HXC200HEC200HGC200HX
Conditions
JMP(04) --- 7.65 22.35 0.313 0.469 0.938
JME(05) --- 7.95 22.65 0.313 0.469 0.938
FAL(06)
FAL numbers 01 to 99 88.6 88.6 0.313 0.469 0.938
()
FAL number 00 86.6 86.6 0.313 0.469 0.938
FALS(07) --- --- (see
note 1)
(see
note 2)
0.313 0.469 0.938
STEP(08) --- 33.1 47.8 0.313 0.469 0.938
15.3 30
SNXT(09) --- 9.25 23.95 0.313 0.469 0.938
SFT(10)
With 1-word shift register 21.05 35.75 R: 8.05 IL: 8.05 JMP:
8.05
With 100-word shift register 117.8 132.5 R: 8.05 IL: 8.05 JMP:
8.05
With 250-word shift register 262.5 277.2 R: 8.05 IL: 8.05 JMP:
8.05
KEEP(11) For IR and SR 23600 to SR 25515 0.208 0.313 0.625 0.208 0.319 0.625
For SR 25600 to SR 51115 0.318 0.469 0.938
CNTR(12)
Constant for SV 19.15 33.85 R: 16.95 IL: 11.65 JMP:
11.65
DM for SV 31.45 46.15 R: 16.95 IL: 11.65 JMP:
11.65
DIFU(13) --- 13.75 28.45 Normal:
13.75
IL: 13.65 JMP:
11.95
DIFD(14) --- 13.65 28.35 Normal:
13.65
IL: 13.55 JMP:
11.85
TIMH(15)
Interrupt Constant for SV 18.35 33.05 R: 25.05 IL: 24.05 JMP:
14.45
Normal cycle 16.55 31.25 R: 21.95 IL:21.05 JMP:
11.25
Interrupt DM for SV 18.35 33.05 R: 37.1 IL: 36.5 JMP:
14.45
Normal cycle 16.55 31.25 R: 34.1 IL: 33.3 JMP:
11.25
WSFT(16) When shifting 1 word 16.45 31.15 0.313 0.469 0.938
When shifting 6,144 words using DM 6.45 ms (see
note 2)
CMP(20) When comparing a constant to a word 0.417 0.625 1.25 0.313 0.469 0.938
When comparing two words 0.521 0.781 1.56
When comparing two DM 35.2 49.9
MOV(21) When transferring a constant to a word 0.417 0.625 1.25 0.313 0.469 0.938
When comparing two words 0.625 0.937 1.87
When transferring DM to DM 33.7 48.4
MVN(22) When transferring a constant to a word 0.417 0.625 1.25 0.313 0.469 0.938
When comparing two words 0.625 0.937 1.87
When transferring DM to DM 34.3 49
BIN(23) When converting a word to a word 19.65 34.35 0.313 0.469 0.938
When converting DM to DM 40.5 55.2
BCD(24) When converting a word to a word 18.25 32.95 0.313 0.469 0.938
When converting DM to DM 39.1 53.8
ASL(25) When shifting a word 12.25 26.95 0.313 0.469 0.938
When shifting DM 23.35 38.05
