373
Instruction OFF execution time (μs)ON execution time (μs)ConditionsInstruction
C200HEC200HGC200HXC200HEC200HGC200HX
Conditions
ASR(26) When shifting a word 11.95 26.65 0.313 0.469 0.938
When shifting DM 22.95 37.65
ROL(27) When rotating a word 13.15 27.85 0.313 0.469 0.938
When rotating DM 24.25 38.95
ROR(28) When rotating a word 13.15 27.85 0.313 0.469 0.938
When rotating DM 24.25 38.95
COM(29) When inverting a word 11.45 26.15 0.313 0.469 0.938
When inverting DM 22.65 37.35
ADD(30) Constant + word → word 16.65 31.35 0.313 0.469 0.938
Word + word→ word 18.45 33.15
DM + DM → DM 50.1 64.8
SUB(31) Constant – word → word 16.65 31.35 0.313 0.469 0.938
Word – word→ word 18.45 33.15
DM – DM → DM 50.1 64.8
MUL(32) Constant × word → word 31.15 45.85 0.313 0.469 0.938
Word × word→ word 32.95 47.65
DM × DM → DM 64.7 79.4
DIV(33)
Word ÷ constant → word
30.15 44.85 0.313 0.469 0.938
Word ÷ word→ word
32.35 47.05
DM ÷ DM → DM
64.1 78.8
ANDW(34) Constant AND word → word 14.35 29.05 0.313 0.469 0.938
Word AND word→ word 15.25 29.95
DM AND DM → DM 46.7 61.4
ORW(35) Constant OR word → word 14.35 29.05 0.313 0.469 0.938
Word OR word→ word 15.25 29.95
DM OR DM → DM 46.7 61.4
XORW(36) Constant XOR word → word 14.35 29.05 0.313 0.469 0.938
Word XOR word→ word 15.25 29.95
DM XOR DM → DM 46.7 61.4
XNRW(37) Constant XNOR word → word 14.55 29.25 0.313 0.469 0.938
Word XNOR word→ word 15.45 30.15
DM XNOR DM → DM 46.9 61.6
INC(38) When incrementing a word 11.55 26.25 0.313 0.469 0.938
When incrementing DM 22.45 37.15
DEC(39) When decrementing a word 11.45 26.15 0.313 0.469 0.938
When decrementing DM 22.35 37.05
STC(40) --- 7.22 21.92 0.313 0.469 0.938
CLC(41) --- 7.22 21.92 0.313 0.469 0.938
TRSM(45) --- 18.65 33.35 0.313 0.469 0.938
MSG(46) Designated as DM 12.05 26.75 0.313 0.469 0.938
Designated as DM 21.95 36.65
ADB(50) Constant + word → word 19.15 33.85 0.313 0.469 0.938
Word + word → word 20.05 34.75
DM + DM → DM 51.7 66.4
SBB(51) Constant – word → word 18.95 33.65 0.313 0.469 0.938
Word – word → word 19.85 34.55
DM – DM → DM 51.7 66.4
Instruction Execution Times Section 6-3
