5 Sysmac Studio Settings for the EtherNet/IP Unit

5-12

CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)

 Trap 1

 Trap 2

*1 These settings are required if the SNMP trap is set is enabled.

*2 Due to Ethernet restrictions, you cannot specify the IP addresses that are described below.

• IP addresses that start with 127, 0, or 255 (decimal)

• Class-D IP addresses (224.0.0.0 to 239.255.255.255)

• Class-E IP addresses (240.0.0.0 to 255.255.255.255)

Setting Description Default

Specifying method Set the specifying method for the SNMP manager destination for SNMP

traps.

• IP address

• Host name

IP address

Set the IP address of the SNMP manager.

(Set this setting if the specifying method in the trap 1 settings is set to the IP

address Option.)

0.0.0.0

Host name Set the host name of the SNMP manager.

(Set this setting if the specifying method in the trap 1 settings is set to the

Host name Option.)

(You can use up to 200 single-byte alphanumeric characters, dots, and

hyphens with up to 63 single-byte alphanumeric characters between dots.)

None

Community name Set the community name.

(You can use up to 200 alphanumeric characters.)

public

Version Set the version of the SNMP manager.

• SNMPv1

• SNMPv2C

SNMPv2C
