Appendices
A-6
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
Additional Information
• The device is found only if it is located below the present cursor position in the Hardware List.
• To search all the devices, select Hardware in the Hardware List before you perform the search
procedure.
To display the properties of the EDS file, use the following procedure.
1 Select the desired hardware (device) from the Hardware List.
2 Select EDS File − Property.
The following dialog box is displayed.
The time and date when the EDS file was created is displayed, along with the device informa-
tion.
To manually add an EDS file or if a device is not displayed correctly in the hardware list, use the follow-
ing procedure to recreate the EDS index file. (This applies to Network Configurator version 3.30 or
higher.)
1 Select EDS File − Create EDS Index File.
2 Restart the Network Configurator.
A-2-6 Displaying EDS File Properties
EDS File − Property
A-2-7 Creating EDS Index Files
EDS File − Create EDS Index File
