Omron CJ1W-EIP21 - A-2-1 Installing EDS Files; A-2-2 Creating EDS Files

Appendices
A-4
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
The Network Configurator can support new devices if the proper EDS files are installed.
To install the EDS file, use the following procedure.
1 Select EDS File − Install.
The Install EDS File Dialog Box is displayed.
2 Select the EDS file to install and click the Open Button. Next, select the icon file (*.ico). The
EDS file is added to the Hardware List as a new device. If the hardware already exists, the new
Hardware List will overwrite the previous one. If the hardware versions are different, a hardware
device is added to the Hardware List for each version.
The EDS files are required by the Network Configurator to create a network configuration. To create an
EDS file, use the following procedure.
1 Select EDS File − Create.
2 Set the device information and I/O information. You can obtain the device information from the
device on the network if the network is online.
3 The device is added to the Hardware List as a new device, just like when you install an EDS file.
Additional Information
You cannot set device parameters with the Network Configurator’s EDS file creation function.
Obtain a proper EDS file from the manufacturer of the device to make device parameter settings
for the device.
A-2-1 Installing EDS Files
EDS File − Install
A-2-2 Creating EDS Files
EDS File − Create
