1 Introduction
1-24
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
Using the Message Communications Service
CIP Communications Instructions
Using the FTP Server
Using the Automatic Clock Adjustment
Using the SNMP Agent
1-5-3 Using EtherNet/IP Network Functions
1
Execute CIP communications instructions in the user program.
Section 8 Message Commu-
nications
2
Check operation.
1-3-2 Part Names and Func-
tions
Section 13 Troubleshooting
Use the Sysmac Studio to check the communications status with the end codes
of the instructions (Done, Err, and ErrorID).
1
Use the Sysmac Studio to set the initial settings of the EtherNet/IP
Function Module.
Section 9 FTP Server
Set the FTP settings (enabling FTP, login name, and password).
2
Connect to the FTP server in the NJ-series CPU Unit from an FTP
client application.
Input the FTP login name and password to log onto the EtherNet/IP Unit.
Check the event log to see if FTP started.
1
Use the Sysmac Studio to set the initial settings of the EtherNet/IP
Function Module.
Section 10 Automatic Clock
Adjustment
Set the SNTP settings (enabling SNTP and execution conditions).
2
Execute automatic clock adjustment.
Execute automatic adjustment at specified times.
1
Use the Sysmac Studio to set the initial settings of the EtherNet/IP
Function Module.
Section 11 SNMP Agent
Set the SNMP settings.
Set the SNMP trap settings
2
Check operation.
Check the event log to see if the SNMP agent started.
