1-25
1 Introduction
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
1-5 EtherNet/IP Communications
Procedures
1
1-5-3 Using EtherNet/IP Network Functions
Using BOOTP
1
Use the Sysmac Studio to set the initial settings of the EtherNet/IP
Function Module.
Section 5 Sysmac Studio
Settings for the EtherNet/IP
Unit
Set the BOOTP settings.
2
Check operation.
Check the event log to see if BOOTP started.
Check online status with the device variables for the CJ-series Unit.
