7-17
7 Tag Data Link Functions
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
7-2 Setting Tag Data Links
7
7-2-1 Starting the Network Configurator
The Main Window consists of a Hardware List and a Network Configuration Pane, as shown in the fol-
lowing diagram.
To manage two or more networks, you can select Network
− Add to add a new Network Configuration
Pane. You can add a new Network Configuration Pane.
To change the name displayed in the Network Tab Page, select Network
− Property. You can change
the name set in the Comment Field of the Network Property Dialog Box.
Main Window
Network Configuration Pane:
This is used to configure the network by placing
devices to be configured and monitored.
Hardware List:
This is a list of devices that
you can add to the network.
