8 Message Communications
8-32
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
(1) Product Codes for Each Model
(2) Status Details of the EtherNet/IP Unit
06 hex Serial Number Serial number Read UINT Set value
07 hex Product Name Product name Read STRING Set value
Type Product Code
NJ501-1300 0665 hex
NJ501-1400 0666 hex
NJ501-1500 0667 hex
NJ301-1100 066B hex
NJ301-1200 066C hex
CJ1W-EIP21(NJ) 0668 hex
Bit Name Description
0 Owned Indicates when the EtherNet/IP Unit has an open connection as the target of
a tag data link.
1 Reserved Always FALSE.
2 Configured Tag data link settings exist.
3 Reserved Always FALSE.
4 to 7 Extended Device Status Indicates the status of the EtherNet/IP Unit.
8 Minor Recoverable Fault TRUE when any of the following errors occurs.
TCP/IP Advanced Setting Error
DNS Server Connection Error
Tag Data Link Setting Error
Tag Data Link Error
Tag Data Link Connection Failed
FTP Server Settings Error
NTP Client Setting Error
SNMP Settings Error
NTP Server Connection Error
Tag Resolution Error
9 Minor Unrecoverable Fault TRUE when the following error occurs.
Identity Error
10 Major Recoverable Fault TRUE when any of the following errors occurs.
IP Address Duplication Error
BOOTP Server Error
Basic Ethernet Setting Error
TCP/IP Basic Setting Error
11 Major Unrecoverable Fault TRUE when any of the following errors occurs.
Communications Controller Error
MAC Address Error
Attribute ID Parameter name Description Attribute
Read data
Data
type
Value
b7 b6 b5 b4
0 1 0 1 There is a major fault.
0 0 1 0 A timeout occurred in one or more target con-
nections.
0 0 1 1 Indicates that there are no tag data link settings.
0 1 1 0 Indicates that one or more connections are per-
forming communications normally.
0 1 1 1 Other than the above.
