11-9
11 SNMP Agent
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
11-1 SNMP Agent
11
11-1-4 MIB Specifications
ipOutNoRoutes (12) RO
The number of IP datagrams that were discarded
because there was no transmission path. This
counter includes datagrams that attempted to be
sent through ipForwDatagrams, but were dis-
carded because they were set with no-route. This
value indicates the number of datagrams that
could not be transferred because the default gate-
way was down.
Sup-
ported.
According to the
standard.
ipReasmTimeout (13) RO
The maximum number of seconds to wait to
receive all IP datagrams for reassembly if a frag-
mented IP datagram is received.
Sup-
ported.
60 s
ipReasmReqds (14) RO
The number of IP datagrams received that require
reassembly. There is a flag in the IP header that
indicates if the datagram is fragmented. You can
use that flag to identify fragments.
Sup-
ported.
According to the
standard.
ipReasmOKs (15) RO
The number of IP datagrams received that were
successfully reassembled.
Sup-
ported.
According to the
standard.
ipReasmFails (16) RO
The number of IP datagrams received that were
not successfully reassembled.
Sup-
ported.
According to the
standard.
ipFragOKs (17) RO
The number of IP datagrams that were success-
fully fragmented.
Sup-
ported.
According to the
standard.
ipFragFails (18) RO
The number of IP datagrams that were not suc-
cessfully fragmented. (For example, because the
Don’t Fragment flag was set for the IP datagram.)
Sup-
ported.
According to the
standard.
ipFragCreates (19) RO
The number of IP datagrams created as a result of
fragmentation.
Sup-
ported.
According to the
standard.
ipAddrTable (20) NA
An address information table for IP addresses.
--- ---
Subtree name Standard [(identifier) attribute]
Sup-
port
Implementation
specifications
