13 Troubleshooting
13-22
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
01 0115 Error code returned from tar-
get:
The Product Type did not
match when opening connec-
tion.
This error does
not occur.
Depends on
the target’s
specifications.
(Contact the
target device’s
manufacturer.)
Confirm that
the target
device’s EDS
file is correct.
Check the origi-
nator’s connec-
tion settings.
01 0116 Error code returned from tar-
get:
The Major/Minor Revisions
did not match when opening
connection.
Check the
major and
minor revisions
set for the tar-
get device and
connection. If
necessary,
obtain the EDS
file and set it
again.
Depends on
the target’s
specifications.
(Contact the
target device’s
manufacturer.)
Confirm that
the target
device’s EDS
file is correct.
Check the origi-
nator’s connec-
tion settings.
01 0117 Error code returned from tar-
get:
The tag set specified in the
connection’s target variables
does not exist.
Check whether
the originator
and target tag
sets and tags
are set cor-
rectly.
Check the set-
tings of the
variables in the
CPU Unit.
Depends on
the target's
specifications.
(Contact the
target device's
manufacturer.)
Check the origi-
nator's connec-
tion settings.
Check whether
the target's tag
sets and tags
are set cor-
rectly.
Check the set-
tings of the
variables in the
CPU Unit.
01 011A Error code returned from orig-
inator:
Connection could not be
established because the buf-
fer was full due to high traffic.
An unexpected
network load
may have been
received. Use
the Network
Configurator
Device Monitor
or the Ethernet
Tab Page to
check the
bandwidth
usage, and cor-
rect the load. If
there are
places where
broadcast
storms occur,
such as loop
connections in
the network
connection for-
mat, then cor-
rect them.
An unexpected
network load
may have been
received. Use
the Network
Configurator
Device Monitor
or the Ethernet
Tab Page to
check the
bandwidth
usage, and cor-
rect the load. If
there are
pl
aces where
broadcast
storms occur,
such as loop
connections in
the network
connection for-
mat, then cor-
rect them.
Follow the
operating spec-
ifications for the
originator.
(Consult the
originator man-
ufacturer.)
Connection status
Source of error
Handling
General
Status
(hex)
Additional
Status
(hex)
Configuration
1
Configuration
2
Configuration
2
