Omron CJ1W-EIP21 User Manual

13-43
13 Troubleshooting
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
13-5 Event Logs
13
13-5-3 Error Descriptions
Event name Ethernet Advanced Setting Error Event code 34AF0000 hex
Meaning There is an illegal FINS setting.
Source PLC Function Module Source details CJ-series Unit Detection
timing
At power ON,
Controller reset,
or Unit restart
Error attributes Level Minor fault Recovery Error reset Log category System
Effects User program Continues. Operation The relevant function stops.
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The power was interrupted during a
download.
Identify the cause of the error from
the detailed information in the error
history of EtherNet/IP Unit, and then
correct the settings.
Make sure that the power supply is
not interrupted during a download.
A communications error occurred dur-
ing a download.
Implement noise countermeasures if
there is excessive noise.
Implement noise countermeasures.
Attached
information
None
Precautions/
Remarks
None
Event name Address Mismatch Event code 34B00000 hex
Meaning The host ID of the local IP address is inconsistent with the FINS node address. Or, the last segment of the local IP
address is inconsistent with the setting on the node address switches.
Source PLC Function Module Source details CJ-series Unit Detection
timing
At power ON,
Controller reset,
or Unit restart
Error attributes Level Minor fault Recovery Error reset Log category System
Effects User program Continues. Operation FINS communications are not possible.
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The IP address conversion method is
set to automatic generation, but the
host ID of the local IP address is
inconsistent with the FINS node
address or the last segment of the
local IP address is inconsistent with
the setting on the node address
switch.
Set the IP address or node address to
match.
None
Attached
information
None
Precautions/
Remarks
None
