Omron CJ1W-EIP21 User Manual

Unit Versions
36
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
 CPU Unit and CJ-series Units
A unit version label is included with the Unit. You can attach the label to the front of the Unit to differ-
entiate it from previous EtherNet/IP Units.
In this manual, unit versions are specified as shown in the following table.
Note The unit version of the EtherNet/IP Unit is sometimes called the revision (“Rev.”) on the Support Software.
There are also places in this manual where the unit version of the EtherNet/IP Unit is called the revision
(“Rev.”).
The following table gives the CIP revision that is supported by the unit version of the EtherNet/IP Unit.
 CJ1W-EIP21
The following versions of the Sysmac Studio and Network Configuration are required to set the Ether-
Net/IP Unit.
 CJ1W-EIP21
The following table gives the CPU Units to which you can connect the EtherNet/IP Unit according to the
unit version of the EtherNet/IP Unit.
* Connect to a CPU Unit with unit version 1.01 or later and use Sysmac Studio version 1.02 or higher.
Identifying the Unit Version on the Unit Version Label
Unit Version Notation
Product nameplate Notation in this manual Remarks
“Ver.1.0” or later to the right of
the lot number
Unit version 1.0 or later Unless unit versions are specified, the information in this manual
applies to all unit versions.
CIP Revision
Unit version CIP revision
2.1 2.04
Unit Versions and Programming Device Versions
Unit version
Sysmac Studio
Version 1.01 or lower Version 1.02
2.1 Not supported. Supported.
Unit version
Network Configurator for EtherNet/IP
Version 3.40 or lower Version 3.50
2.1 Not supported. Supported.
Unit Versions and Applicable CPU Units
Unit version
CPU Unit
CJ-series CPU Unit NJ-series CPU Unit
2.0 or earlier Supported. Not supported.
2.1 or later Supported. Supported.*

Omron CJ1W-EIP21 Specifications

General

Brand	Omron
Model	CJ1W-EIP21
Category	Controller
Language	English
