The following table gives the unit version of the CPU Units and the Sysmac Studio version that
are required to specify member offsets.
* You cannot select the memory offset type. You can set member offsets.
If you change the memory configuration of a structure variable by setting offsets, you must make the
same changes for the same structure variable in other NJ-series CPU Units on the network.
Refer to the Sysmac Studio Version 1 Operation Manual (Cat. No W504-E1-03 or higher) for the pro-
cedure to change the memory configuration of a structure variable.
Example: The following example shows how the memory configuration of the structure variable
members in the NJ-series CPU Unit is changed to match the memory configuration of the structure
variable members in the CJ-series CPU Unit.
Unit version of CPU Unit
Sysmac Studio version
1.01 or lower 1.02 1.03 or higher
1.01 or later Not possible. Possible.* Possible.
1.00 Not possible. Not possible. Not possible.
