Omron CJ1W-EIP21 User Manual

Appendices
A-26
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
The device variables that correspond to bits 00 to 15 in CIO n+2 to n+5 are given in the following
table.
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit number Variable name Description
CIO n+2 0 *_TargetPLCMdSta[0] Target Node PLC Operating Flag for Node
Address 0
1 *_TargetPLCMdSta[1] Target Node PLC Operating Flag for Node
Address 1
2 *_TargetPLCMdSta[2] Target Node PLC Operating Flag for Node
Address 2
3 *_TargetPLCMdSta[3] Target Node PLC Operating Flag for Node
Address 3
4 *_TargetPLCMdSta[4] Target Node PLC Operating Flag for Node
Address 4
5 *_TargetPLCMdSta[5] Target Node PLC Operating Flag for Node
Address 5
6 *_TargetPLCMdSta[6] Target Node PLC Operating Flag for Node
Address 6
7 *_TargetPLCMdSta[7] Target Node PLC Operating Flag for Node
Address 7
CIO n+2 8 *_TargetPLCMdSta[8] Target Node PLC Operating Flag for Node
Address 8
9 *_TargetPLCMdSta[9] Target Node PLC Operating Flag for Node
Address 9
10 *_TargetPLCMdSta[10] Target Node PLC Operating Flag for Node
Address 10
11 *_TargetPLCMdSta[11] Target Node PLC Operating Flag for Node
Address 11
12 *_TargetPLCMdSta[12] Target Node PLC Operating Flag for Node
Address 12
13 *_TargetPLCMdSta[13] Target Node PLC Operating Flag for Node
Address 13
14 *_TargetPLCMdSta[14] Target Node PLC Operating Flag for Node
Address 14
15 *_TargetPLCMdSta[15] Target Node PLC Operating Flag for Node
Address 15
