Omron CJ1W-EIP21 User Manual

Appendices
A-44
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
 Words x+16 to x+31: Normal Target Node Table
The device variable that corresponds to all of the bits in words x+16 to x+31 is given in the following
table.
Word x+15 0 *_x.RegTargetSta.Target-
Sta[240]
Registered Target Node Table Bit for Node
Address 240
.
.
.
.
.
.
.
.
.
15 *_x.RegTargetSta.Target-
Sta[255]
Registered Target Node Table Bit for Node
Address 255
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit numbers Variable name Description
Words x+16 to
x+31
00 to 15 in
each word
*_x.EstbTarget-
Sta.TargetStaWd
Normal Target Node Table
(The functions of bits 00 to 15 in these words and
the functions of the device variable given on the left
correspond as given below.)
• Bits 00 to 15 of word x+16 correspond to bits 00 to
15 of the device variable given on the left.
• Bits 00 to 15 of word x+17 correspond to bits 16 to
31 of the device variable given on the left.
• Bits 00 to 15 of word x+18 correspond to bits 32 to
47 of the device variable given on the left.
• Bits 00 to 15 of word x+19 correspond to bits 48 to
63 of the device variable given on the left.
• Bits 00 to 15 of word x+20 correspond to bits 64 to
79 of the device variable given on the left.
• Bits 00 to 15 of word x+21 correspond to bits 80 to
95 of the device variable given on the left.
• Bits 00 to 15 of word x+22 correspond to bits 96 to
111 of the device variable given on the left.
• Bits 00 to 15 of word x+23 correspond to bits 112
to 127 of the device variable given on the left.
• Bits 00 to 15 of word x+24 correspond to bits 128
to 143 of the device variable given on the left.
• Bits 00 to 15 of word x+25 correspond to bits 144
to 159 of the device variable given on the left.
• Bits 00 to 15 of word x+26 correspond to bits 160
to 175 of the device variable given on the left.
• Bits 00 to 15 of word x+27 correspond to bits 176
to 191 of the device variable given on the left.
• Bits 00 to 15 of word x+28 correspond to bits 192
to 207 of the device variable given on the left.
• Bits 00 to 15 of word x+29 correspond to bits 208
to 223 of the device variable given on the left.
• Bits 00 to 15 of word x+30 correspond to bits 224
to 239 of the device variable given on the left.
• Bits 00 to 15 of word x+31 correspond to bits 240
to 255 of the device variable given on the left.
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit number Variable name Description
